2019 GMC Sierra 1500 Limited

2019 GMC Sierra 1500 Limited

2WD Double Cab

View more styles
Close

All 2019 GMC Sierra 1500 Limited Styles

Style NameFuel TypeDrive TypeMPGMSRP
2WD Double CabGasoline FuelRear Wheel DriveCity: 15
Hwy: 15
$35,100.00
2WD Double Cab SLEGasoline FuelRear Wheel DriveCity: 15
Hwy: 15
$40,300.00
4WD Double CabGasoline FuelFour Wheel DriveCity: 15
Hwy: 15
$39,100.00
4WD Double Cab SLEGasoline FuelFour Wheel DriveCity: 15
Hwy: 15
$43,700.00

2WD Standard Pickup Trucks
Rear Wheel Drive
Base MSRP: $35,100.00
Invoice: $33,590.70
Hwy MPG: 22 mpg
City MPG: 15 mpg

Pricing

To get up to date 2019 GMC Sierra 1500 Limited values, we highly recommend you evaluate and compare the Retail, Private Party, and/or Trade-In Values from the following reputable market pricing providers:

Exterior Color Interior Colors


Stone Blue Metallic

Manufacturers Code: (G1K)

  • Dark Ash seats with Jet Black interior accents
  • Dark Ash seats with Jet Black interior accents


Summit White

Manufacturers Code: (GAZ)

  • Dark Ash seats with Jet Black interior accents
  • Dark Ash seats with Jet Black interior accents


Cardinal Red

Manufacturers Code: (G7C)

  • Dark Ash seats with Jet Black interior accents
  • Dark Ash seats with Jet Black interior accents


Quicksilver Metallic

Manufacturers Code: (GAN)

  • Dark Ash seats with Jet Black interior accents
  • Dark Ash seats with Jet Black interior accents


Onyx Black

Manufacturers Code: (GBA)

  • Dark Ash seats with Jet Black interior accents
  • Dark Ash seats with Jet Black interior accents


Dark Slate Metallic

Manufacturers Code: (GPA)

  • Dark Ash seats with Jet Black interior accents
  • Dark Ash seats with Jet Black interior accents


Deep Mahogany Metallic

Manufacturers Code: (G2X)

  • Dark Ash seats with Jet Black interior accents
  • Dark Ash seats with Jet Black interior accents

Vehicle

Emissions
Tons/yr of CO2 Emissions @ 15K mi/year10.3
EPA Greenhouse Gas ScoreN/A

Chassis

Weight Information
Gross Axle Wt Rating - Front3650 lbs
Gross Axle Wt Rating - Rear3950 lbs
Curb Weight - Front2919 lbs
Curb Weight - Rear2064 lbs
Option Weight - Front0.00 lbs
Option Weight - Rear0.00 lbs
Reserve Axle Capacity - Front731.00 lbs
Reserve Axle Capacity - Rear1886.00 lbs
As Spec'd Curb Weight4983.00 lbs
As Spec'd Payload2017.00 lbs
Maximum Payload Capacity2017.00 lbs
Gross Combined Wt Rating15000 lbs
Gross Axle Weight Rating7600.00 lbs
Curb Weight4983.00 lbs
Reserve Axle Capacity2617.00 lbs
Total Option Weight0.00 lbs
Gross Vehicle Weight Rating7000.00 lbs
Trailering
Dead Weight Hitch - Max Trailer Wt.5000 lbs
Dead Weight Hitch - Max Tongue Wt.500 lbs
Wt Distributing Hitch - Max Trailer Wt.9400 lbs
Wt Distributing Hitch - Max Tongue Wt.940 lbs
Maximum Trailering CapacityN/A
Frame
Frame TypeHydroformed
Sect Modulus Rails OnlyN/A
Frame RBMN/A
Frame StrengthN/A
Frame ThicknessN/A
Suspension
Suspension Type - FrontIndependent
Suspension Type - Rear2-Stage Multi-Leaf
Spring Capacity - Front3850 lbs
Spring Capacity - Rear3950 lbs
Axle Type - FrontIndependent
Axle Type - RearSemi-floating
Axle Capacity - Front3850 lbs
Axle Capacity - Rear3950 lbs
Axle Ratio (:1) - Rear3.42
Shock Absorber Diameter - Front46.00 mm
Shock Absorber Diameter - Rear35.00 mm
Stabilizer Bar Diameter - Front1.35 in
Tires
Front Tire Order CodeRBZ
Rear Tire Order CodeRBZ
Spare Tire Order CodeZBZ
Front Tire SizeP255/70R17
Rear Tire SizeP255/70R17
Spare Tire SizeP255/70R17
Front Tire CapacityN/A
Rear Tire CapacityN/A
Spare Tire CapacityN/A
Revolutions/Mile @ 45 mph - FrontN/A
Revolutions/Mile @ 45 mph - RearN/A
Revolutions/Mile @ 45 mph - SpareN/A
Wheels
Front Wheel Size17 x 8.0 in
Rear Wheel Size17 x 8.0 in
Spare Wheel Size17 x -TBD- in
Front Wheel MaterialSteel
Rear Wheel MaterialSteel
Spare Wheel MaterialN/A
Steering
Steering TypeElectric Rack & Pinion
Steering Ratio (:1), OverallN/A
Steering Ratio (:1), On CenterN/A
Steering Ratio (:1), At LockN/A
Turning Diameter - Curb to Curb46.9 ft
Turning Diameter - Wall to WallN/A
Brakes
Brake TypePwr
Brake ABS System4-Wheel
Disc - Front (Yes or )Yes
Disc - Rear (Yes or )Yes
Front Brake Rotor Diam x Thickness13.00 x 1.18 in
Rear Brake Rotor Diam x Thickness13.60 x 0.79 in
Fuel Tank
Fuel Tank Capacity, Approx26 gal
Fuel Tank LocationN/A

Powertrain

Transmission
DrivetrainRear Wheel Drive
Trans Order CodeMYC
Trans Type6
Trans Description Cont.Automatic
First Gear Ratio (:1)4.00
Second Gear Ratio (:1)2.40
Third Gear Ratio (:1)1.50
Fourth Gear Ratio (:1)1.20
Fifth Gear Ratio (:1)0.90
Sixth Gear Ratio (:1)0.70
Reverse Ratio (:1)3.10
Final Drive Axle Ratio (:1)N/A
Mileage
EPA Fuel Economy Est - Hwy22 MPG
Cruising Range - City390.00 mi
EPA Fuel Economy Est - City15 MPG
Fuel Economy Est-Combined17 MPG
Cruising Range - Hwy572.00 mi
Engine
Engine Order CodeL83
Engine TypeGas V8
Displacement5.3L/325
Fuel SystemDirect Injection
SAE Net Horsepower @ RPM355 @ 5600
SAE Net Torque @ RPM383 @ 4100
Engine Oil CoolerYes
Electrical
Cold Cranking Amps @ 0° F (Primary)720
Cold Cranking Amps @ 0° F (3rd)N/A
Maximum Alternator Capacity (amps)150
Cooling System
Total Cooling System CapacityN/A

Dimensions

Interior Dimensions
Passenger Capacity6
Front Head Room42.80 in
Front Leg Room45.27 in
Front Shoulder Room65.93 in
Front Hip Room60.73 in
Second Head Room38.67 in
Second Leg Room34.63 in
Second Shoulder Room65.80 in
Second Hip Room60.23 in
Exterior Dimensions
Wheelbase143.50 in
Length, Overall w/o rear bumper229.50 in
Length, Overall w/rear bumperN/A
Length, OverallN/A
Width, Max w/o mirrors80.00 in
Height, Overall73.87 in
Overhang, FrontN/A
Overhang, Rear w/o bumperN/A
Front Bumper to Back of Cab141.37 in
Cab to Axle41.50 in
Cab to End of FrameN/A
Ground to Top of Load Floor34.8 in
Ground to Top of FrameN/A
Frame Width, RearN/A
Ground Clearance, Front8.47 in
Ground Clearance, Rear8.47 in
Body Length0.00 ft
Cab to BodyN/A
Cargo Area Dimensions
Cargo Box Length @ Floor78.87 in
Cargo Box Width @ Top, RearN/A
Cargo Box Width @ Floor64.9 in
Cargo Box Width @ Wheelhousings51.03 in
Cargo Box (Area) Height21.10 in
Tailgate WidthN/A
Cargo Volume61.00 ft³
Ext'd Cab Cargo VolumeN/A

Warranty Information

<<< Preliminary 2019 Warranty Note >>>

Basic:
3 Years/36,000 Miles

Drivetrain:
5 Years/60,000 Miles
Qualified Fleet Purchases: 5 Years/100,000 Miles

Corrosion:
3 Years/36,000 Miles
Rust-Through
6 Years/100,000 Miles

Roadside Assistance:
5 Years/60,000 Miles
Qualified Fleet Purchases: 5 Years/100,000 Miles

Maintenance:
1 Year/1 Visit

Crash Test Rating

US NHTSA CRASH TEST RESULTS:

Overall Rating: * * * * *

Overall Frontal Barrier Crash Rating: * * * * *
Driver: * * * * * Passenger: * * * * *

Overall Side Crash Rating: * * * * *

Side Barrier Rating: * * * * *
Driver: * * * * * Rear Passenger: * * * * *

Side Pole Rating Driver Front Seat: * * * *

Combined Side Barrier and Pole Ratings:
Front Seat Rating: * * * * * Rear Seat Rating: * * * * *

Overall Rollover Rating: * * * *
Dynamic Test Result: No Tip
Risk of Rollover: 17.40%

Note Regarding Driver Rating:

Male: Average sized adult male dummy in 35-MPH crash into fixed barrier. Rating is evaluation of injury to head, neck, chest, legs. Female: Small-sized adult female dummy in 35-mph crash into fixed barrier. Rating is evaluation of injury to head, neck, chest, legs.

Rollover Note: Dynamic (moving) test results (Tip or No Tip) and measured rollover-related properties determine vehicle's risk of rollover in single vehicle crash and its rollover rating. The Rollover Resistance Rating utilizes a "fishhook" maneuver which is a series of abrupt turns at varying speeds to see how "top-heavy" a vehicle is.
